SL.K.U.3-3 WINKHAUS proPILOT top frame hinge

WINKHAUS XR 04 N 30/60 core with a "butterfly"

А-30

В-60

WINKHAUS ACTIVPILOT FL.K.U.6 loop at the lower sash.

Art. 4940180

Extension of the WINKHAUS MK.500-1 blockade, fittings model ACTIVPILOT

WINKHAUS XR 04 N 40/40 core with a "butterfly"

А-40

В-40

WINKHAUS GAM.800 castle.

Model fitting WINKHAUS ACTIVPILOT.

The Winkhaus STV T-U2460 L01 R4 MC multifunctional lock is a modern solution for PVC, aluminum, and wood entrance doors. Its central locking system and additional cylindrical rollers (R4) ensure stable pressure between the door leaf and frame, enhancing the door's seal and durability. The MC coating protects components from corrosion and extends the life of the mechanism.

Applications:

PVC, aluminum, and wood entrance doors,

single-leaf doors,

areas requiring high pressure and secure locking.

Corner transmission of Wink Haus fittings (Winkhaus) proPilot series (pro pilot) with one mushroom-shaped trunnion and one standard.

The corner switch is designed to ensure the transmission of movement from the movable part of the tilt-and-turn lock through the sash corner to the subsequent parts of the perimeter trim.

It is installed on plastic (PVC) windows and balcony doors exclusively with WinkHaus fittings proPilot series.

With an additional mushroom-shaped pin that fixes the sash in the tilt.

Adjustable sash pressure to the frame +/- 0.8 mm.

Size 159x159 mm.

Universal element - for right and left opening.

Visible additional clamp, metal, white.

WINKHAUS OS2.1250-1 SL

Model fitting ACTIVPILOT.

The Winkhaus DS.24 child lock (Germany) allows you to restrict the opening of the sash in the swing position, but it does not limit the operation of the sash in the ventilation mode.

The appearance of the window does not deteriorate, since the lock is installed by cutting into the sash. Locking with a key provides protection from children and increases the security of windows from breaking.

Angle ER 3-0

Model of fittings WINKHAUS AUTOPILOT

Used on narrow sashes with upper rail OR 600

WINKHAUS hinge KB.K. 20-13

Bar width 16 mm

Fixed in the fitting groove with latches, maximum sash weight 80 kg

Installed with bracket loop SL.KS

WINKHAUS FWV RS reinforced loop at the lower sash (Art. 1945188), right.

HAUTAU DUOPORT SK 100/160 LS set, left

Trolleys for sliding doors.

Extension WINKHAUS MVR 50/2, model fitting WINKHAUS AUTOPILOT.
