Corner transmission of Wink Haus fittings (Winkhaus) proPilot series (pro pilot) with one mushroom-shaped trunnion and one standard.

The corner switch is designed to ensure the transmission of movement from the movable part of the tilt-and-turn lock through the sash corner to the subsequent parts of the perimeter trim.

It is installed on plastic (PVC) windows and balcony doors exclusively with WinkHaus fittings proPilot series.

With an additional mushroom-shaped pin that fixes the sash in the tilt.

Adjustable sash pressure to the frame +/- 0.8 mm.

Size 159x159 mm.

Universal element - for right and left opening.

Extension WINKHAUS M.500-1, fittings model ACTIVPILOT

Product Name: FK 20-6/20

Brand: WINKHAUS

Hinge Type: Overhead

Location: Bottom

Purpose: PVC

WINKHAUS T.13/3 microventilation

Art. 4937780

WINKHAUS STV-FG 1660/35 92/8 R4 SL multi-point lock, handle closure.

R4- 4 pressure drums, D35, 92 system.

WINKHAUS XR 04 N 50/50 core with a "butterfly"

А-50

В-50

WINKHAUS STV-FG 2060/45 92/8 M2 LS SL multi-point lock, LEFT, handle locking.

Hinge WINKHAUS ACTIVPILOT EL.K.SE.152. RS (right)

Art. 4938496.

By order.

WINKHAUS STV-FG 1660/45 92/8 M2 RS SL multi-point lock, handle locking.

, D55, 92 system.

WINKHAUS XR 04 N 60/30 core with a "butterfly"

А-60

В-30

HAUTAU HKS130 FFB 1250 WS set for sliding doors.

WINKHAUS XR 04 N 45/40 core with a "butterfly"

А-45

В-40

WINKHAUS ACTIVPILOT SK2.20-13 RS Bracket

Article 2842586.

Supplied without plastic lining.

ExtensionWINKHAUS MVR 35/1 WK,modelfittingAUTOPILOT.

Art. 1110469.

Angle E1

WINKHAUS ACTIVPILOT fittings model

Art. 2841823

Original Winkhaus A-13/9/U BL insert bracket from the STV series (locks for armored doors).

Manufacturer number: 1424551 "T-EINZATZW. A-13/9/U B
