Original Winkhaus A-13/9/U BL insert bracket from the STV series (locks for armored doors).

Manufacturer number: 1424551 "T-EINZATZW. A-13/9/U B

WINKHAUS AUTOPILOT SWTF 22-18/9-12 RS Bracket for wooden windows, right

Special balcony latch BK 60 for PVC profiles REHAU, VEKA, KÖMMERLING, SCHÜCO 60, SCHÜCO 70.

Universal, for the left and right side.

An additional fit for the above profiles is not required.

Visible additional clamp, metal, brown.

Set in fitting groove to further clamp hidden in the design of PVC, wood and aluminum.

Angle E1

WINKHAUS FLEX fittings model

Art. 1157414

WINKHAUS ACTIVPILOT SK2.20-13 RS Bracket

Article 2842586.

Supplied without plastic lining.

Extension of the WINKHAUS MK.500-1 blockade, fittings model ACTIVPILOT

WINKHAUS XR 04 N 45/60 core with a "butterfly"

А-45

В-60

The sash rotation limiter at a certain angle makes it possible to open at an angle of up to 90 degrees.

Does not depend on the type of fittings.

The minimum rebate size (horizontal length of the fitting groove) of the sash is 460 mm.

Product type: Corner ER 15 WK AUTOPLOT

Window material: aluminum wood plastic steel

Mounting groove of the door leaf: Mounting groove 16 mm

Installation side: DIN left, DIN right

Gap of the cut - threshold: -1.00 mm

Mounting position: Bottom hinge Vertical frame at the top Vertical frame at the bottom

Type of fixing point: Eccentric roller pin WK

Number of locking points: 2.00

WINKHAUS XR 04 N 45/40 core with a "butterfly"

А-45

В-40

WINKHAUS ACTIVPILOT FL.K.20-6-20 loop at the lower sash.

Used in combination with the lower frame loop EL.K.6-3-16 WINKHAUS ACTIVPILOT Loop (ref:EL.K.6-3-16)

Art. 4928429

WINKHAUS GAM.1800-2 castle.

Model fitting ACTIVPILOT, type - burglar, has 2 pcs. 8-sided "fungus" with the ability to manually adjust the clamp.

WINKHAUS STV-FG 1660/45 92/8 RT 4 SL multi-point lock, handle locking.

R4- 4 clamps, 2 rollers and 2 anti-burglar, D45, 92 system.

WINKHAUS XR 04 N 35/45 core with a "butterfly"

А-35

В-45

WSK 226 SL WINKHAUS ( TROCAL) return part
