Multi-point universal door lock with roller FUHR 35/16 R4.

The width of the bar is 16 mm, 4 rollers.

Lock striker FUHR FRA for FUHR door locks for GEALAN and DECCO profile, right (RS).

U 252 х 25 mm

WINKHAUS STV-FG 1660/35 92/8 R4 SL multi-point lock, handle closure.

R4- 4 pressure drums, D35, 92 system.

Fix Asgard 7025( PZ Lock Centre : 70/92 mm) Latch 3 Hooks Double Spindle Multipoint Door Lock - Option 2 (top hook to spindle = 730mm)

WINKHAUS STV-FG 1660/55 92/8 R4 SL multi-point lock, handle locking.

R4- 4 pressure drums, D55, 92 system.

WINKHAUS STV-F 1660/26 92/8 R4 SL Multipoint door lock.

Сlosing of the cylinder.

WINKHAUS STV-FG 1660/40 92/8 R4 SL multi-point lock, handle locking.

R4- 4 pressure drums, D40, 92 system.

Lock striker FUHR FRA for FUHR door locks for GEALAN and DECCO profile, left (LS).

U 252 х 25 mm

Multi-point universal door lock FUHR 45/16 R4 FG.

The width of the bar is 16 mm, 4 rollers.

Multi-point lock-rail with handle control.

Multi-point locks-rails are designed for more reliable locking of doors made of profile structures, primarily metal-plastic. Non-slip locking points do not allow the door to be easily squeezed

Parameters

Rack length 2200 mm

Control From handle

Latch type Latch

Bar Yes

Center distance 92 mm

Backset 45 mm

Door height 1600-2000mm, R4- 4 pressure drums, D45, 92 system.

Multi-point lock, closing from the handle.

WINKHAUS STV-FG 1660/45 92/8 R4 SL multi-point lock, handle locking.

R4- 4 pressure drums, D45, 92 system.

WINKHAUS STV-F 1660/35 92/8 M2 LS SL Multipoint locking of the handle - you turn the knob up to 45 degrees is a movement of the locking elements.

The final closing of the core is made.

Fixing plate for STV fitting (2 pieces) U-shaped faceplate 26 mm, option -76, SKG certified, MV2, matt chrome plated (silver)

Set.

WINKHAUS STV-FG 1660/45 92/8 M2 LS SL multi-point lock, handle locking.

, D45, 92 system.
