WINKHAUS AUTOPILOT SWTF 22-18/9-12 RS Bracket for wooden windows, right

ROTO NT upper loop without pin

ROTO NT Axerarm K 500 12/20-13 RS bracket, right, the size of the sash FFB 801-1400 mm.

Art. 258043.

WINKHAUS STV-F 1660/35 92/8 M2 RS SL multi-point lock from the handle - when the handle is turned upwards by 45 degrees, the locking elements move.

The final locking is performed by the core.

ROTO NT Axerstulp 500/890 top part (801-1000 mm)

Art. 260208.

WINKHAUS SWN top hinge on the frame for PVC windows for FLEX, AUTOPILOT fittings.

Set: universal balcony latch, 2 formteil, handle PS plastic, white.

ALS-FSS microlift block RS- when closing the sash of the window block, this additional WINKHAUS window hardware element raises the sagging sash by a few millimeters relative to the lower frame profile.

Corner transmission of Wink Haus fittings (Winkhaus) proPilot series (pro pilot) with one mushroom-shaped trunnion and one standard.

The corner switch is designed to ensure the transmission of movement from the movable part of the tilt-and-turn lock through the sash corner to the subsequent parts of the perimeter trim.

It is installed on plastic (PVC) windows and balcony doors exclusively with WinkHaus fittings proPilot series.

With an additional mushroom-shaped pin that fixes the sash in the tilt.

Adjustable sash pressure to the frame +/- 0.8 mm.

Size 159x159 mm.

Universal element - for right and left opening.

WINKHAUS STV-F 2060/45 92/8 R4 SL multi-point lock, core locking.

Door height 1800-2000mm, R4- 4 pressure drums, D45, 92 system.

ROTO NT SH-Schließstück, Rehau, 13V, Boden, Zink against breaking plank.

Art. 316942.

ROTO NT model of fittings Abdeckkappe Ecklager K Lasche, white pad on the loop.

Art. 230426.

HAUTAU DUOPORT SK 100/160 LS set, left

Trolleys for sliding doors.

Lock striker FUHR FRA for FUHR door locks for GEALAN profile, left (LS).

U 252 х 25 mm

Original Winkhaus A-13/9/U BL insert bracket from the STV series (locks for armored doors).

Manufacturer number: 1424551 "T-EINZATZW. A-13/9/U B

Product type: Corner ER 15 WK AUTOPLOT

Window material: aluminum wood plastic steel

Mounting groove of the door leaf: Mounting groove 16 mm

Installation side: DIN left, DIN right

Gap of the cut - threshold: -1.00 mm

Mounting position: Bottom hinge Vertical frame at the top Vertical frame at the bottom

Type of fixing point: Eccentric roller pin WK

Number of locking points: 2.00
