The Winkhaus STV T-U2460 L01 R4 MC multifunctional lock is a modern solution for PVC, aluminum, and wood entrance doors. Its central locking system and additional cylindrical rollers (R4) ensure stable pressure between the door leaf and frame, enhancing the door's seal and durability. The MC coating protects components from corrosion and extends the life of the mechanism.

Applications:

PVC, aluminum, and wood entrance doors,

single-leaf doors,

areas requiring high pressure and secure locking.

ROTO anti-theft bracket

The set includes 4 pieces, a complete set, white color. Suitable only for the WINKHAUS ProPilot fittings model.

Roto NT bottom corner

Corner transmission of Wink Haus fittings (Winkhaus) proPilot series (pro pilot) with one mushroom-shaped trunnion and one standard.

The corner switch is designed to ensure the transmission of movement from the movable part of the tilt-and-turn lock through the sash corner to the subsequent parts of the perimeter trim.

It is installed on plastic (PVC) windows and balcony doors exclusively with WinkHaus fittings proPilot series.

With an additional mushroom-shaped pin that fixes the sash in the tilt.

Adjustable sash pressure to the frame +/- 0.8 mm.

Size 159x159 mm.

Universal element - for right and left opening.

ROTO NT Axerarm K 350 12/20-13 LS bracket, left, the size of the sash FFB 601-800 mm.

Art. 258064.

The sash rotation limiter at a certain angle makes it possible to open at an angle of up to 90 degrees.

Does not depend on the type of fittings.

The minimum rebate size (horizontal length of the fitting groove) of the sash is 460 mm.

SIEGENIA TITAN AF/PSK 1S corner

Application of PVC. Wood.

Repair cassette for ROTO NT locks.

Fasten with screws.

NB! Before purchasing, make sure the cassette and internal sprocket are compatible with your gearing.

Extension of the WINKHAUS MK.750-1 blockade, fittings model ACTIVPILOT

SEF 1/105 EF VEKA SOFTLINE AD 9mm, KBE AD - burglar-proof contour element

ROTO NT GR.1100 lock (801-1100)

Product name SK.U.1.20-13. proPilot bracket left

Manufacturer WINKHAUS

proPilot system

Opening side Left

Marking (mounting axis) 13

Window material PVC

WINKHAUS WSK 162 reply part (Schließstück)

Art. 1211582

Multi-point universal door lock FUHR 25/16 R4 FG.

The width of the bar is 16 mm, 4 rollers.

GAMA 2300-3 D35 WINKHAUS ACTIVPILOT lock

Dormas 35 mm
